Hydraulic Power Unit

Model: LY-ADC25

• Model: LY-ADC25
• Rated Capacity:2500KG
• Load Center Distance :50MM
• Power Mode:Lead-Acid Battery
• Wheel Base:1600MM
• Travel Speed, Laden/Unladen: 9/10km/h
• Lifting Speed, Laden/Unladen: 210/250mm/s
• Lowering Speed, Laden/Unladen: 450mm/s
• Maximum Negoniable Gradient,Laden/Unladen: 15/20%
• Service Mass(with battery): 3150KG
• Battery Voltage / Nominal Capacity: 72V/210Ah
• Battery Weiaht: 360
• Drive Motor Power-60 Minutes(KW): 9 Permanent Magnet Synchronization
• Lift Motor Power-15 Minutes(KW):7.5 Permanent Magnet Synchronization
• Drive Motor Controlling Mode: MOSFET/AC
• Lifting Motor Controlling Mode:MOSFET/AC
• Service Brake/Parking Brake:Hydraul ic/Mechanial
• Tyre Type:Solid Tire
• Wheels Number (front/rear): 2/2
• Front Track: 1010MM
• Rear Track: 880MM
• Tyre (front): 6.5 -10
• Tyre (rear): 16*6-8
• Front Overhang: 410MM
• Tilt Of The Mast,Front/Rear（°）: 5/10
• Height, Mast Retraction: 2030MM
• Overall Maximum Lift Height: 3000MM
• Height,mast extended: 4055MM
• Overhead Guard Height: 2110MM
• Lateral Fork Adjustment (Outside Of Forks)Max/Min: 1040/100MM
• Fork Size(L*W*T): 40*100*1070
• Truck Body Length(Fork Excluded): 2390MM
• Truck Body Width: 1160MM
• Turning Radius: 2370MM
• Groubd Clearance Under Mast: 88MM
• Ground Clearance At Center Of Wheelbase(Laden): 110MM
• Width Of Aisle Right-Angle Stacking(pallet 1000x1000mm clearance 200mm): 3750MM
• Width Of Aisle Right-Angle Stacking(pallet 1200x1200mm clearance 200mm): 3950MM
• Level 2 3m mast, permanent magnet synchronous motor, battery 72V210Ah (12 pieces), hydraulic steering, solid tires,
• Intelligent charger, fork length 1070mm, cast iron counterweight,Domestic side shifter, suspension seat, rear headlights, double rearview mirrors, warning lights, increase fork tooth sleeve 1500mm,220V charger + US standard plug

Model: LY-WA02

• Engine: Briggs & Stratton gasoline engine 13.5HP
• KOOP192F Euro 5 diesel engine 10HP
• total measurement
• Overall length (when transported): 2870 mm
• Overall width (transport/work): 930 mm
• Overall height (with/without roof): 2285 (2030) mm
• Dozer blade width: 937mm
• Dozer blade height: 210mm
• Track center distance: 746 mm
• Standard track shoe width: 180mm
• Platform ground clearance: 405 mm
• Standard bucket width (with/without teeth): 380/330 mm
• Track length: 1200mm
• The scope of work
• Maximum digging height: 2490 mm
• Maximum unloading height: 1745mm
• Maximum digging depth: 1725mm
• Maximum vertical digging depth: 1655mm
• Maximum digging radius: 3030mm
• Minimum turning radius: 1490 mm
• Maximum digging ground distance: 2940 mm
• Maximum dozing height: 170 mm
• Deepest dozing height: 240mm
• Basic parameters
• Working weight: 1300kg
• Bucket capacity: 0.022 cubic meters
• Working device form: backhoe

Model: LY-10

• RATED POWER:9KW/12HP
• BUCKET CAPACITY:0.022 CUBIC METERS
• ENGINE MODEL: BRIGG&STRATTON GASOLINE ENGINE
• MAXUMUM EXCAVATION FORCE:7.5KN
• SET WORKING PRESSURE:25MPA
• SPEED:12 RPM
• WALKING SPEED:3 KILOMETERS PER HOUR
• CLIMBING ABILTY:30 DEGREES
• GROUND SPECIFIC VOLTAGE :19 KPA
• SIDE SWAY ANGLE:3010MM
• MAXIMUM EXCAVATION DISTANCE:1520MM
• MAXIMUM EXCAVATION HEIGHT:2400MM
• MAXIMUM UNLOADING HEIGHT:1610MM
• MINIMUM TURNING RADIUS:1360MM
• MAXIMUM GROUND CLEARANCE OF BULLDOZER:140MM
• MAXIMUM SUPPORT DEPTH OF BULLDOZER:200MM
• TRACK WIDTH(FASTENING SCREW):830(880)MM
• TOTAL HEIGHT(SHED):1370(2080)MM
• TOTAL LENGHT:2780MM
• TRACK GROUND LENGTH:1140MM
• Installation: 1. Quick changer, 2. Hydraulic thumb clamp, 3.20cm narrow bucket, 4.80cm toothless flat bucket, 5.800*200 screw Rotary drill (including drive, hydraulic pipe), 6. rake, 7. ripper, 8. air filter, 9. tool box
