pecifications

Operation Weight   1900kg

Rated Power      14hp/10.2kw/3000r/min

Max. Grade Ability   30

Fuel Tank Capacity   11L

Hydraulic Tank Capacity  19L

Max.Torque   42.9/2000(N.m/r/m)

Flow Rate    22+6.6L/Min

Dimensions

Total Length  3110mm

Total Width  1000mm-1250mm

Total Height  2280(2242)mm

Bulldozer Blade Height  213mm

Bulldozer Blade Depth  1100mm

Track Length    1472mm

Platform Back Swing Radius  1000mm

Wheelbase  870mm

Chassis Width  1080mm

Track Shoe Width  230mm

Engine Modle  Kubota D722

Digging Bucket Capacity  0.03m3

Travel Speed   2km/h

Swing Speed  l0rpm

Engine Oil Capacity  3.2L

Operating Pressure  16MPa

Displacement  0.719L

Working Range

Max Digging Height  3010mm

Max. Dumping Height  2285mm

Max. Digging Depth 2050mm

Max. Digging Radius 3260mm

Max Digging Reach at Ground Level 2940mm

Min. Turning Radius 1100mm

Max Bulldozer Lifting Height 220mm

Max Bulldozer Digging Depth 290mm

Model: LY-ADC25

• Model: LY-ADC25
• Rated Capacity:2500KG
• Load Center Distance :50MM
• Power Mode:Lead-Acid Battery
• Wheel Base:1600MM
• Travel Speed, Laden/Unladen: 9/10km/h
• Lifting Speed, Laden/Unladen: 210/250mm/s
• Lowering Speed, Laden/Unladen: 450mm/s
• Maximum Negoniable Gradient,Laden/Unladen: 15/20%
• Service Mass(with battery): 3150KG
• Battery Voltage / Nominal Capacity: 72V/210Ah
• Battery Weiaht: 360
• Drive Motor Power-60 Minutes(KW): 9 Permanent Magnet Synchronization
• Lift Motor Power-15 Minutes(KW):7.5 Permanent Magnet Synchronization
• Drive Motor Controlling Mode: MOSFET/AC
• Lifting Motor Controlling Mode:MOSFET/AC
• Service Brake/Parking Brake:Hydraul ic/Mechanial
• Tyre Type:Solid Tire
• Wheels Number (front/rear): 2/2
• Front Track: 1010MM
• Rear Track: 880MM
• Tyre (front): 6.5 -10
• Tyre (rear): 16*6-8
• Front Overhang: 410MM
• Tilt Of The Mast,Front/Rear（°）: 5/10
• Height, Mast Retraction: 2030MM
• Overall Maximum Lift Height: 3000MM
• Height,mast extended: 4055MM
• Overhead Guard Height: 2110MM
• Lateral Fork Adjustment (Outside Of Forks)Max/Min: 1040/100MM
• Fork Size(L*W*T): 40*100*1070
• Truck Body Length(Fork Excluded): 2390MM
• Truck Body Width: 1160MM
• Turning Radius: 2370MM
• Groubd Clearance Under Mast: 88MM
• Ground Clearance At Center Of Wheelbase(Laden): 110MM
• Width Of Aisle Right-Angle Stacking(pallet 1000x1000mm clearance 200mm): 3750MM
• Width Of Aisle Right-Angle Stacking(pallet 1200x1200mm clearance 200mm): 3950MM
• Level 2 3m mast, permanent magnet synchronous motor, battery 72V210Ah (12 pieces), hydraulic steering, solid tires,
• Intelligent charger, fork length 1070mm, cast iron counterweight,Domestic side shifter, suspension seat, rear headlights, double rearview mirrors, warning lights, increase fork tooth sleeve 1500mm,220V charger + US standard plug

Model: LY-WA02

• Engine: Briggs & Stratton gasoline engine 13.5HP
• KOOP192F Euro 5 diesel engine 10HP
• total measurement
• Overall length (when transported): 2870 mm
• Overall width (transport/work): 930 mm
• Overall height (with/without roof): 2285 (2030) mm
• Dozer blade width: 937mm
• Dozer blade height: 210mm
• Track center distance: 746 mm
• Standard track shoe width: 180mm
• Platform ground clearance: 405 mm
• Standard bucket width (with/without teeth): 380/330 mm
• Track length: 1200mm
• The scope of work
• Maximum digging height: 2490 mm
• Maximum unloading height: 1745mm
• Maximum digging depth: 1725mm
• Maximum vertical digging depth: 1655mm
• Maximum digging radius: 3030mm
• Minimum turning radius: 1490 mm
• Maximum digging ground distance: 2940 mm
• Maximum dozing height: 170 mm
• Deepest dozing height: 240mm
• Basic parameters
• Working weight: 1300kg
• Bucket capacity: 0.022 cubic meters
• Working device form: backhoe
